Pistón Rammer S84 (10455) – Alto rendimiento para tu martillo hidráulico

Si buscas durabilidad, potencia de impacto y ajuste perfecto, este pistón está fabricado para ofrecer el máximo rendimiento en aplicaciones de demolición, cantera y minería.

Especificaciones técnicas:

Longitud: 40.39 in

Diámetro: 6.50 in

Peso: 282.01 lb

Código: 10455

Compatibilidad: Rammer S84 / Sandvik serie equivalente

 Características destacadas:

Fabricado en acero aleado de alta resistencia

Tratamiento térmico para máxima vida útil

Acabado mecanizado con tolerancias OEM

Balance perfecto para minimizar vibración y desgaste interno

 Beneficios para tu operación:

Mayor fuerza de impacto

Menor consumo de energía del equipo

Reducción de paradas por mantenimiento

Rendimiento constante incluso en trabajo pesado

 Disponibilidad: En stock – envío rápido.
 Solicita precio o cotización internacional: info@meritautomotive.com
 Exportamos a todo el mundo.

Housing Unit S84
10459, Housing,
30578, Spacer plate,
30274, Buffer,
41131, Pad,
40540, Spring,
90520, Hex. screw M36x140-8.8,
90521, Washer 39,
90519, Lock nut M36-8,
41104, Wear plate,
41110, Pin,
41112, Pin,
41148, Shim plate,
41109, Pin,
41118, Ring,
900026, Hex. screw M30x40-8.8,
90705, Lifting eye M30,
200231, Label set,

Accumulator S84
30270, Accumulator,
42078, Washer,
30261, Accumulator screw,
10230, Accumulator bottom,
10231, Accumulator cover,
30269, Membrane,
40528, Accumulator screw,
40368, Filling plug,
40536, Seal D144,
400300, Shield plug,
90056, Ustr-ring U8.7-14-1,
90304, Parallel pin 10m6x24,
910006, O-ring D23,

Main Valve S84
20183, Main valve bushing,
30267, Main spool,
40524, Spool,
40523, Spool,
30260, Cover,
30295, Cover,
90032, O-ring D120,
90033, O-ring D125,
91010, Lock washer M20,
90518, Hex. screw M20x1.5×45-10.9,

Check Valve S84
40587, Check valve,
90597, Lock washer M16,
90517, Hex. screw M16x35-8.8,
30272, Check valve housing,
90432, Check valve,
90310, Spring ring B38,
90403, Flange plug R1/4,
90031, O-ring D46,
90007, O-ring D44,

Pressure Control Valve S84
31691, Pressure control valve,
30580, Cover,
30268, Valve housing,
40527, Guide,
31430, Spool,
40522, Spool,
40525, Spring guide,
90118, Spring,
90030, O-ring D75,
40533, Seal D65,
40534, Seal D55,
42361, Shim plate S=1.5,
42362, Shim plate S=1.25,
42363, Shim plate S=0.9,
42099, Spring support,

Tie Rods S84
30608, Tie rod,
300291, Tie rod nut,
41090, Lock plate,
40586, Rubber ring,
901025, O-ring D54,

Body Parts S84
10409, Valve body,
10461, Cylinder,
10510, Seal carrier,
10455, Piston,
41140, Seal D239,
41141, Seal D143,
90073, Seal D145,
90075, Seal D130,
41192, Seal D130,
90003, O-ring D239,
41194, Wiper D130,
90072, Wiper D145,
90410, Flange plug R1,
90424, Flange plug R1/2,
90317, Parallel pin 16m6x50,
101700, Breather,
901173, O-ring D27,
400485, Flange,
90555, Hex. socket screw M10x25-8.8,

Front Head S84
10745, Front head,
20623, Thrust ring,
30558, Upper tool bushing,
41479, Tool retaining pin,
40110, Wedge,
41130, Retaining pin D26,
40503, Retaining pin D40,
901134, Split pin Connex 40×70,
40116, Plug,
90000, O-ring D24,
90110, Spring D25x64,
90200, Grease nipple R1/4,
41325, Retaining pin D10,
90319, Split pin 10×16,

Lower Tool Bushing S84
102158, Lower tool bushing,
102322, Seal,
20319, Lower tool bushing, hard,
20943, Lower tool bushing, standard,

Seal Set S84
41241, Seal set,
41140, Seal D239,
41141, Seal D143,
90073, Seal D145,
90075, Seal D130,
41192, Seal D130,
90000, O-ring D24,
90032, O-ring D120,
90033, O-ring D125,
90003, O-ring D239,
41194, Wiper D130,
90072, Wiper D145,
901173, O-ring D27,
901025, O-ring D54,
40536, Seal D144,
90056, Ustr-ring U8.7-14-1,
90030, O-ring D75,
40533, Seal D65,
40534, Seal D55,
90031, O-ring D46,
90007, O-ring D44,
910006, O-ring D23,

S84 W-Model Parts
30714, Housing,
10509, Piston,
93629, Hose L=680,
93042, Coupling SR25,
90008, O-ring D25.0x3.53,
90404, Split flange 251-12,
90504, Hex. socket screw M10x30-8.8,
