Krupp HM 1000 and HM 1000 Marathon s
1. Working Tools (Outils à emmancher)
Page 3
| Part Number | Description (Original) | Description (English) |
| 3067143 | Pointerolle (outil universel) | Moil Point (Universal tool) |
| 3067145 | Burin plat, transversal | Flat Chisel (Crosscut) |
| 3067119 | Pilon (pétardage) | Blunt Tool (Ramming) |
| 3066065 | Graisse spéciale Krupp (500 g) | Special Krupp Grease (500g Cartridge) |
2. Main Percussion Unit (Marteau Hydraulique)
Page 4
| Part Number | Description (Original) | Description (English) |
| 3033001 | Marteau hydraulique HM 1000 | Hydraulic Breaker HM 1000 |
| 3066178 | Marteau hydraulique HM 1000 Marathon | Hydraulic Breaker HM 1000 Marathon |
| 3033003 | Culasse de cylindre complète (31 cpl.) | Cylinder Head Complete |
| 3067047 | Douille d’étanchéité complète (41 cpl.) | Sealing Bush Complete |
| 3066027 | Cylindre | Cylinder |
| 3033049 | Piston de frappe | Percussion Piston |
| 3070038 | Partie inférieure du marteau (Marathon) | Lower Breaker Part (Marathon) |
| 3070037 | Partie inférieure du marteau (Standard) | Lower Breaker Part (Standard) |
| 3034294 | Tirant cpl. | Tie Rod Complete / Through Bolt |
| 0478171 | Joint torique | O-Ring |
| 3067187 | Rondelle | Washer |
| 3033051 | Douille de centrage | Centering Bush |
| 1850519 | Accumulateur de pression | High Pressure Accumulator |
| 1031912 | Joint torique | O-Ring |
| 1850529 | Bague d’appui | Back-up Ring |
| 1333703 | Rondelle d’arrêt | Lock Washer |
| 0026648 | Vis à tête cylindrique | Socket Head Screw |
| 0996719 | Soupape de remplissage cpl. | Filling Valve Complete |
| 0175125 | Joint torique | O-Ring |
| 2328126 | Joint torique | O-Ring |
| 2263820 | Bague à rainures | U-Packing / Grooved Ring |
| 2267557 | Joint en U à lèvres | Buffer Seal / U-Seal |
| 2267558 | Racleur | Wiper / Dust Seal |
| 1854657 | Vis de raccordement | Connection Screw |
| 0433774 | Graisseur conique | Grease Nipple |
| 1031794 | Bouchon fileté | Threaded Plug |
| 2267584 | Bague d’étanchéité | Seal Ring |
| 2267589 | Bague d’étanchéité | Seal Ring |
| 0478169 | Joint torique | O-Ring |
| 3031859 | Bague d’appui | Back-up Ring |
| 3033029 | Couvercle | Cover |
| 1331555 | Vis à tête cylindrique | Socket Head Screw |
| 0103776 | Bouchon vissé | Screw Plug |
| 0314375 | Joint torique | O-Ring |
| 3035425 | Douille d’étanchéité | Sealing Bush |
| 3067325 | Bague section carrée | Square Ring |
| 0107881 | Joint torique | O-Ring |
| 0314370 | Bague d’étanchéité | Seal Ring |
| 3035453 | Soupape complète | Control Valve Complete |
| 3067117 | Tiroir de pilotage | Control Spool |
| 3031872 | Douille de retenue | Retaining Bush |
| 0479721 | Axe de retenue | Retaining Pin |
| 3031973 | Douille de retenue | Retaining Bush |
| 2263821 | Bouchon | Plug |
| 0478426 | Bouchon fileté | Threaded Plug |
| 1031529 | Insert fileté | Threaded Insert |
| 1031946 | Insert fileté | Threaded Insert |
| 1031989 | Insert fileté | Threaded Insert |
| 1844113 | Disque filtrant | Filter Disc |
| 1844115 | Bouchon vissé | Screw Plug |
| 0206598 | Anneau à vis | Screw Ring / Lifting Eye |
| 3068027 | Bague d’impact | Impact Ring |
| 3031774 | Insert fileté | Threaded Insert |
| 3069195 | Douille d’usure (DustProtector) | Wear Bush (DustProtector) |
| 3069193 | Douille d’usure | Wear Bush |
| 0106074 | Vis à tête cylindrique | Socket Head Screw |
| 2261563 | Rondelle d’arrêt | Lock Washer |
| 0314372 | Joint torique | O-Ring |
| 1353488 | Bouchon fileté | Threaded Plug |
| 3069191 | Douille d’usure | Wear Bush |
| 3066028 | Coiffe anti-poussière | Dust Cap |
| 3066069 | Racleur de l’outil | Tool Wiper |
| 2261647 | Membrane cpl. | Diaphragm Complete |
| 3034311 | Jeu de joints | Seal Kit |
3. Hammer Box / Casing (Caisson du marteau)
Pages 5 & 7
| Part Number | Description (Original) | Description (English) |
| 3070010 | Caisson complet (Marathon) | Hammer Box Complete (Marathon) |
| 3070011 | Caisson complet (Standard) | Hammer Box Complete (Standard) |
| 3033467 | Elément amortisseur | Damping Element / Upper Cushion |
| 3033465 | Amortisseur | Shock Absorber / Buffer |
| 3035795 | Plaque | Plate |
| 3035793 | Plaque de guidage | Guide Plate |
| 3035773 | Bague libre | Floating Ring |
| 3035775 | Contre-bague | Counter Ring |
| 3035777 | Bague de guidage | Guide Ring |
| 3066048 | Bague anti-poussière | Dust Ring |
| 3033027 | Axe de retenue | Retaining Pin |
| 3033043 | Douille de retenue | Retaining Bush |
| 2262093 | Sécurité de transport | Transport Safety Device |
| 0026883 | Vis à tête cylindrique | Socket Head Screw |
| 1850747 | Rondelle d’arrêt | Lock Washer |
| 0103254 | Ecrou hexagonal | Hex Nut |
| 3070182 | Plaquette CE | CE Plate |
| 3066074 | Jeu de pièces en plastique (Marathon) | Plastic Parts Kit (Marathon) |
| 3066502 | Jeu de pièces en plastique (Standard) | Plastic Parts Kit (Standard) |
| 3033551 | Coiffe (ouverture de visite) | Cover (Inspection Opening) |
| 2267894 | Bouchon | Plug |
| 2267898 | Bouchon | Plug |
4. Lubrication & Connections (Graissage / ContiLube)
Pages 6 & 8
| Part Number | Description (Original) | Description (English) |
| 3068939 | Plaque | Plate |
| 0103750 | Boulon à tête cylindrique | Socket Head Bolt |
| 1850596 | Rondelle de retenue | Retaining Washer / Lock Washer |
| 2269857 | Adapteur pour agent lubrifiant | Lubricant Adapter |
| 3066233 | Raccord fileté orientable | Swivel Fitting |
| 3066231 | Conduite de graisse | Grease Line |
| 3066887 | Raccord-union | Union Fitting |
| 3068745 | Raccord-union | Union Fitting |
| 3066227 | Raccord fileté orientable | Swivel Fitting |
| 3066051 | Tuyau hydraulique | Hydraulic Hose |
| 3066951 | Bague d’étanchéité | Seal Ring |
| 3068937 | Plaque pour ContiLube® II | Plate for ContiLube II |
| 3066234 | Raccord fileté orientable | Swivel Fitting |
